III - 28
Service Procedures
SM830063
3
1. Troubleshooting
Never press CL (clear) button unless you want to erase the accessed data in memory. Follow the procedure below only
when erasing is necessary.
❏ To erase accessed data, press the CL button.
❏ When erasing is finished,“----” mark appears on the controller’s display.
After checking the alarm messages, be sure to press the TEST / CHK button.
(E) Check the remote controller itself for correct operation
The remote controller has a self-diagnostic function to check if it works properly. Use this procedure to find out if the
remote controller itself is in trouble.
a Turn ON the RCU.CK switch on the back of the P.C.B. Ass’y in the remote controller. See section (A) for exact
location.
b The appearance of the display will tell you whether or not the remote controller is working correctly or not.
❏ Normal condition – All displays appear for 10 seconds, then disappear.
❏ Unusual condition – All displays flash ON and OFF for 10 seconds, then disappear.
After checking the panel, be sure to set the RCU.CK switch to this original OFF position.
Important
CAUTION
CAUTION
To Next Page
