SM830063
I - 135
1
ECO MULTI SYSTEM Unit Specifications
11-1. Specifications
Unit specifications (A)
11. 1-Way Air Discharge Semi-concealed-Slim Type (SL Type)
MODEL No. Indoor Unit SPW-SLR93GH56
POWER SOURCE 220 - 230 - 240 V / 1 phase / 50Hz
PERFORMANCE Cooling Heating
Capacity kW 2.8 3.2
BTU / h 9,600 11,000
Air circulation (Hi / Me / Lo) m
3
/h 840 (750)* / 630 / 540
Moisture removal (High) Liters/h 0.6 —
ELECTRICAL RATINGS
Voltage rating V 220 230 240 220 230 240
Available voltage range V 198 – 264
Running amperes A 0.50 0.50 0.51 0.36 0.37 0.38
Power input W 105 110 115 75 80 85
Power factor % 95 96 94 95 94 93
Fan motor locked rotor amperes A 1 11111
FEATURES
Controls Microprocessor
Timer ON / OFF Timer (Max. 72 hr)
Fan speeds 3 and Automatic control
Air filter Washable, easy access, long life (2,500 hr)
Refrigerant control Electronic expansion valve
Operation sound (Hi / Me / Lo) dB-A 43 (41)* / 36 / 33
Refrigerant tubing connections Flare type
Refrigerant tube diameter Narrow tubemm (in.) 9.52 (3 / 8)
Wide tube mm (in.) 12.7 (1 / 2)
Drain connection 25 A, OD32 mm
Drain pump Max. head 25 cm above drain connection
Remote Controller Optional (RCS-SH80TG)
Refrigerant tubing kit / Accessories Optional / —
Color (Approximate value) Munsell 10Y9.3 / 0.4, RAL 9010-GL
DIMENSIONS & WEIGHT Indoor Unit Package
(include panel) Body Panel
Dimensions Height mm (in.) 213 ( 8-12/32) 365 (14-12/32) 164 ( 6 -15/32)
Width mm (in.) 1,233 (48-17/32) 1,268 (49-29/32) 1,393 (54-27 /32)
Depth mm (in.) 730 (28-24/32) 714 (28- 4/32) 860 (33-27/32)
Net weight kg (lbs.) 34 (75) — —
Shipping weight kg (lbs.) — 32 (71) 13 (29)
Shipping volume m
3
(cu. ft) — 0.33 (11.7) 0.196 (6.9)
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
*: When using accessory cable
Rated conditions
Cooling: Indoor air temperature 27 °CDB/19 °C WB, Outdoor air temperature 35 °C DB
Heating: Indoor air temperature 20 °C DB , Outdoor air temperature 7 °CDB/6 °CWB
