SM830063
I-51
1
ECO MULTI SYSTEM Unit Specifications
4-1. Specifications
Unit specifications (A)
4. 1-Way Air Discharge Semi-concealed Type
MODEL No. Indoor Unit SPW-ASR93GH56
POWER SOURCE 220 - 230 - 240 V / 1 phase / 50Hz
PERFORMANCE Cooling Heating
Capacity kW 2.8 3.2
BTU / h 9,600 11,000
Air circulation (Hi / Me / Lo) m
3
/ h 480 / 420 / 360
Moisture removal (High) Liters / h 1.1 —
ELECTRICAL RATINGS
Voltage rating V 220 - 230 - 240
Available voltage range V 198 – 264
Running amperes A 0.36 - 0.37 - 0.38 0.28 - 0.29 - 0.30
Power input W 65 - 70 - 75 50 - 55 - 60
Power factor % 82 - 82 - 82 81 - 82 - 83
Fan motor locked rotor amperes A 1 - 1 - 1
FEATURES
Controls Microprocessor
Timer ON / OFF Timer (Max. 72 hr)
Fan speeds (Indoor unit) 3 and Automatic control
Air filter Washable, easy access
Refrigerant control Electronic expansion valve
Operation sound (Hi / Me / Lo) dB-A 34 / 32 / 30
Refrigerant tubing connections Flare type
Refrigerant tube Narrow tube mm (in.) 9.52 (3 / 8)
diameter Wide tube mm (in.) 12.7 (1 / 2)
Drain connection 25 A, OD32 mm
Drain pump Max. head 25 cm above drain connection
Remote Controller Optional (RCS-SH80TG)
Refrigerant tubing kit / Accessories Optional / —
Color (Approximate value) Munsell 10Y9.3 / 0.4, RAL 9010-GL
DIMENSIONS & WEIGHT (include ceiling panel) Unit dimensions Package dimensions
Dimensions Height mm (in.) 370 (14 - 5 / 8) 485 (19 - 1 / 8)
Width mm (in.) 810 ( 31 - 7 / 8) 918 ( 38 - 1 / 8)
Depth mm (in.) 620 ( 24 - 3 / 8) 728 ( 28 - 5 / 8)
Net weight kg (lbs.) 28 ( 62 )
Shipping weight kg (lbs.) 40 ( 88 )
Shipping volume m
3
(cu. ft) 0.324 ( 11.6 )
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Rated conditions
Cooling: Indoor air temperature 27 °CDB/19 °C WB, Outdoor air temperature 35 °C DB
Heating: Indoor air temperature 20 °C DB , Outdoor air temperature 7 °CDB/6 °CWB
To Next Page
