I-62
SM830063
ECO MULTI SYSTEM Unit Specifications
1
5. Wall Mounted Type
5-2. Major component specifications
Indoor unit (A)
MODEL No. SPW-KR93GH56
Source 220 - 230 - 240 V / 1 phase / 50Hz
Controller P.C.B. Ass’y CR-X253GH (Microprocessor)
Fan (Number…diameter) mm Cross-flow (1 … ø 81 / L 610)
Fan motor
Model…Nominal output W UF2Q-21C5P … 20 W
Source 220 - 230 - 240 V / 1 phase / 50 Hz
No. of pole…r.p.m. (230 V, High) rpm. 2 … 1,170
Coil resistance Ω BRN – WHT : 208.5 ORG – YEL : 72.32
(Ambient temperature 20 °C) WHT – VLT : 84.20 YEL – PNK : 44.89
VLT – ORG : 17.59
Safety device
Operating temperature Open °C 130 ± 5
Close °C (115 ± 5)
Run capacitor VAC, µF 440 V, 0.8 µF
Electronic expansion valve
Coil LAM-MD12ST-1
Coil resistance (at 20 °C) Ω ORG – RED : 48 , YEL – BRN : 48
RED – WHT : 48 , BRN – BLU : 48
Valve body LAM-B30YPST-1
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows…fin pitch mm 2 … 1.5
Face area m
2
0.172
Auto louver motor M2LJ24ZE31
Rated AC 230 V-50 Hz
No. of pole…r.p.m. rpm. 8P – 2.5
Nominal output W 3
Coil resistance (at 25 °C) Ω 16.450 Ω ± 15 %
