ECO MULTI SYSTEM Unit Specifications
SM830063
I-21
1
0272_C_I
90
80
70
60
50
40
30
20
10
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
63 125 250 500 1000 2000 4000 8000
BAND CENTER FREQUENCIES, Hz
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
NC-70
NC-60
NC-50
NC-30
NC-20
NC-40
MODEL : SPW-CR903GVH8 , CR903GV8
SOUND LEVEL : HIGH 58 dB(A), NC 52
CONDITION : Height 1 m, distance 1 m
SOURCE : 380 / 400 / 415 V, 3 Phase, 50 Hz
1. Outdoor Unit
1-7. Noise criterion curves
MODEL : SPW-CR703GVH8 , CR703GV8
SOUND LEVEL : HIGH 58 dB(A), NC 52
CONDITION : Height 1 m, distance 1 m
SOURCE : 380 / 400 / 415 V, 3 Phase, 50 Hz
0272_C_I
90
80
70
60
50
40
30
20
10
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
63 125 250 500 1000 2000 4000 8000
BAND CENTER FREQUENCIES, Hz
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
NC-70
NC-60
NC-50
NC-30
NC-20
NC-40
90
80
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
0658_X_S
BAND CENTER FREQUENCIES, Hz
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
NC-70
NC-50
NC-20
NC-60
NC-40
NC-30
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0dB=0.0002 µbar)
90
80
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
0658_X_S
BAND CENTER FREQUENCIES, Hz
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
NC-70
NC-50
NC-20
NC-60
NC-40
NC-30
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0dB=0.0002 µbar)
MODEL : SPW-CR363GVH8 , CR363GV8
SOUND LEVEL : 54 dB(A), NC 45
CONDITION : Distance 1 m, Hight 1 m
SOURCE : 220 - 230 - 240 V, 1 Phase, 50 Hz
380 - 400 - 415 V, 3 Phase, 50 Hz
MODEL : SPW-CR483GVH8 , CR483GV8
SOUND LEVEL : 56 dB(A), NC 47
CONDITION : Distance 1 m, Hight 1 m
SOURCE : 380 - 400 - 415 V, 3 Phase, 50 Hz
