I-81
SM830063
1
ECO MULTI SYSTEM Unit Specifications
7-1. Specifications
Unit specifications (A)
MODEL No. Indoor Unit SPW-UR93GH56
POWER SOURCE 220 - 230 - 240 V / 1 phase / 50Hz
PERFORMANCE Cooling Heating
Capacity kW 2.8 3.2
BTU / h 9,600 11,000
Air circulation (Hi / Me / Lo) m
3
/ h 480 / 440 / 330
Moisture removal (High) Liters / h 1.3 —
External static pressure (High) 5 (49): at shipment, 10 (98): using the booster cable
ELECTRICAL RATINGS
Voltage rating V 220 - 230 - 240
Available voltage range V 198 – 264
Running amperes A 0.37 - 0.4 - 0.43 0.37 - 0.4 - 0.43
Power input W 80 - 90 - 100 80 - 90 - 100
Power factor % 98.3 - 97.8 - 96.9 98.3 - 97.8 - 96.9
Max. starting amperes A 1 - 1 - 1
FEATURES
Controls Microprocessor
Timer ON / OFF Timer (Max. 72 hr)
Fan speeds 3 and Automatic control
Air filter Field supply
Refrigerant control Electronic expansion valve
Operation sound (Hi / Me / Lo) dB-A 30 / 26 / 22
using the booster cable (Hi / Me / Lo)
dB-A 36 / 33 / 28
Refrigerant tubing connections Flare type
Refrigerant tube Narrow tube mm (in) 9.52 (3 / 8)
outer diameter Wide tube mm (in) 12.7 (1 / 2)
Drain pump (drain connection) Max. head 25 cm above drain connection (25A, OD32mm)
Remote controller (option) Optional (RCS-SH80TG)
DIMENSIONS & WEIGHT Unit dimensions Package dimensions
Dimensions Height mm (in) 310 (12 - 7 /32) 380 (14 --31/32)
Width mm (in) 750 (29 - 17 /32) 949 (37 --12/32)
Depth mm (in) 665 (26 - 6 /32) 866 (34 - 3 /32)
Net weight kg (lb) 31 ( 68 )
Shipping weight kg (lb) 37 ( 82 )
Shipping volume m
3
(cu. ft) 0.312 ( 11 )
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Cooling :
Rating conditions : Indoor air temperature 27 °C DB / 19 °C WB, Outdoor air temperature 35 °C DB
Heating :
Rating conditions : Indoor air temperature 20 °C DB, Outdoor air temperature 7°C DB / 6°C DB
7. Concealed Duct Type
