SM830063
I-27
1
ECO MULTI SYSTEM Unit Specifications
2. 4-Way Air Discharge Semi-concealed Type
2-2. Major component specifications
Indoor unit (A)
MODEL No. SPW-XR123GH56
Source 220 - 230 - 240 V / 1 phase / 50Hz
Controller P.C.B. Ass’y CR-X253GH (Microprocessor)
Fan (Number…diameter) mm Turbo (1 … ø 490)
Fan motor
Model…Nominal output W SFG6X-41A5P … 40 W
Source 220 - 230 - 240 V / 1 phase / 50 Hz
No. of pole…r.p.m. (230 V, High) rpm. 6 … 442
Coil resistance Ω BRN – WHT : 114.0 ORG – YEL : 66.4
(Ambient temperature 20°C) WHT – VLT : 23.9 WHT – PNK : 77.4
VLT – ORG : 12.4 YEL – BLK : 82.1
Safety device
Operating temperature Open °C 130 ± 8
Close °C(79± 15 )
Run capacitor VAC, µF 440 V , 3.5 µF
Electronic expansion valve
Coil DKV-MOZS582E0
Coil resistance (at 20°C) Ω ORG – GRY : 46 , YEL – GRY : 46
RED – GRY : 46 , BLK – GRY : 46
Valve body IKV-24D12
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows…fin pitch mm 2…1.5
Face area m
2
0.295
Panel
Model No. PNR-X253GHA
Dew proof heater 240 V, 26 W
Auto louver motor M2LB24ZA12
Auto louver motor…Rated V, W, rpm. 240 VAC, 3W, 2.5 rpm
Coil resistance (at 25 °C) Ω 15.620 Ω ± 15 %
Drain Pump WP20SL - 21
Rated V, W AC230 V, 50 Hz, 14.7 W
Total head & capacity 400 mm, 600 cc/min
