PN-L803C_80TC3 FIRMWARE UPDATE PROCEDURES 5 - 1
CHAPTER 5. FIRMWARE UPDATE PROCEDURES
1. FIRMWARE UPDATE
1-1. OVERVIEW
Main firmware and LAN firmware are updated through this tool. Follow the steps below to update the firmware:
[Data included in Main firmware]
Content Description
Main firmware It handles video picture display.
Sub firmware It handles power source and the LAN control
DP RX firmware It handles signals for Displayport.
DP TX firmware It handles signals for Displayport.
DSD (FRC) firmware It handles double-speed device.
KEY firmware It handles the electrostaic button.
TP FW firmware It handles touch panel control
TP CON firmware It handles touch panel control
1- 2. OPERATION OF FIRMWARE UPDATE
Firmware is updated according to the operation flow shown below.
The firmware can be written via network or the USB flash drive.
Update result is displayed.
Restart
(Automatically)
Check the update
procedure and perform the
update again from the
beginning.
Start
- Writing firmware via USB flash drive
- Writing firmware via network
Sub Firmware update
(Automatically)
Failed
End
Main Firmware update
(Automatically)
-DPTX -DPRX
-Main -SUB
Touch panel Firmware
update (Automatically)
-TPFW
-TPCON
- DSD -KEY
Success
Success
