PN-L803C/80TC3 CONTENTS
CHAPTER 7. TROUBLESHOOTING
1. THE POWER IS NOT SUPPLIED (THE LED DOES NOT LIGHT UP) 7-1
2. THE REMOTE CONTROL DOES NOT WORK 7-2
3. THE DISPLAY DOES NOT WORK/ DISPLAY ABNORMALITY 7-2
4. THE BACKLIGHT DOES NOT LIGHT UP 7-3
5. SOUND IS NOT OUTPUTED/ OUTPUT SOUND ABNORMALITY 7-3
6. DISPLAYPORT(DP) OUTPUT IS NOT MADE / DISPLAY ABNORMALITY 7-4
7. CAN NOT CONTROL LAN CONNECTION (LAN FOR DISPLAY) 7-4
8. THE RED LED FLASHES (DISPLAY ABNORMALITY IS SET) 7-5
9. THE LED LIGHTS UP IN ORDER OF RED 3 GREEN (TEMPERATURE ERROR)
7-5
10. TOUCH PANEL ABNORMALITY 7-6
11. TOUCH PEN ABNORMALITY 7-11
CHAPTER 8. HARDWARE DESCRIPTIONS
1. CIRCUIT DESCRIPTIONS 8-1
2. CAPACITANCE TOUCH PANEL THEORY BASIS 8-6
3. BLOCK DIAGRAM 8-7
4. CONNECTOR TABLE 8-18
5. PARTS LAYOUT 8-21
