PN-L803C/80TC3 CONTENTS
CONTENTS
CHAPTER 1. OUTLINE OF THE PRODUCTS
1. MAIN FEATURE 1-1
2. SPECIFICATION 1-4
3. PART NAMES AND FUNCTION 1-10
4. SCREEN DISPLAY 1-14
CHAPTER 2. INSTALLATION / SETTINGS
1. INSTALLATION 2-1
2. ADJUSTMENT 2-11
3. OTHER SETTING 2-31
4. TOUCH PEN PREPARATION 2-34
5. TOUCH PANEL PREPARATION 2-36
6. TOUCH ACTION 2-39
CHAPTER 3. IMPORTANT INFORMATION FOR SERVICING THE DISPLAY
1. MAIN PWB, LCD MODULE UNIT, T-CON PWB, TOUCH PANEL UNIT REPLACEMENT
PROCEDURES 3-1
2. TEMPORARY STAND 3-3
CHAPTER 4. SERVICE MENU/VARIOUS SETTING TOOL OPERATING PROCEDURES
1. OPERATING PROCEDURES 4-1
2. AGING 4-2
3. CALIBRATION 4-2
4. FACTORY RESET 4-4
5. HARDWARE CHECK 4-5
6. OTHER FUNCTIONS 4-7
7. INSTRUCTIONS FOR LAUNCHER TOOL 4-12
8. SERIAL NUMBER WRITING PROCEDURES 4-15
9. USAGE TIME SETTING PROCEDURE 4-16
10. MODEL NAME SETTING PROCEDURES 4-17
11. USER SETTING TOOL OPERATION PROCEDURES 4-18
12. OPERATING MANUAL OF THE LOG TOOL 4-20
13. SAVE LOG TO THE USB FLASH DRIVE 4-26
14. WHITE BALANCE SETTING TOOL BY OSD 4-27
15. WHITE BALANCE SETTING TOOL OPERATING PROCEDURE 4-30
