PN-L803C/80TC3 CONTENTS
16. GAMMA SETTING PROCEDURES WITH THE OSD 4-32
17. GAMMA SETTING TOOL OPERATION PROCEDURES 4-34
18. TEST PATTERN TOOL 4-36
19. FLICKER ADJUSTMENT TOOL 4-37
20. TOUCH PANEL CALIBRATION TOOL 4-42
21. SENSOR CHECK TOOL 4-44
22. RESET THE ASSIGNED COM PORT NUMBER FOR TOUCH PEN 4-48
23. MAIL DESCRIPTION CONTENT 4-50
24.
CHANGE TOUCH PEN COMMUNICATION CHANNEL(EXTERNAL PC)
4-53
CHAPTER 5. FIRMWARE UPDATE PROCEDURES
1. FIRMWARE UPDATE 5-1
2. HOW TO UPDATE MAIN FIRMWARE VIA NETWORK 5-4
3. HOW TO UPDATE MAIN FIRMWARE VIA USB FLASH DRIVE 5-6
4. EDID WRITING PROCEDURE 5-10
5. TOUCH PEN, TOUCH PEN ADAPTOR FIRMWARE UPDATE 5-12
CHAPTER 6. DISASSEMBLY AND ASSEMBLY
1. PWB AND WIRNG DIAGRAM 6-1
2. HANDLE 6-2
3. REAR COVER R/ L/C 6-3
4. LED POWER SUPPLY PWB 6-5
5. 5V POWER SUPPLY PWB 6-7
6. AC RELAY PWB 6-8
7. T-CON PWB 6-9
8. AFE PWB 6-10
9. DBE PWB 6-11
10. MAIN PWB 6-12
11. KEY PWB 6-14
12. TOUCH PANEL UNIT 6-16
13. LCD MODULE UNIT 6-20
14. SPEAKER R 6-28
15. SPEAKER L 6-29
