Accessories
A.3 Cabinet feedthrough / antenna coupling
LOGO! CMR2020, LOGO! CMR2040
160 Operating Instructions, 10/2016, C79000-G8976-C356-03
Cabinet feedthrough / antenna coupling
Cabinet feedthrough
Cabinet feedthrough / coupling piece
6GK5798-2PP00-2AA6 Cabinet feedthrough for wall thicknesses up to a maximum 4.5 mm, can also be used
as a coupling device between two antenna connecting cables, N-Connect/N-Connect
female/female connector, suitable for 0 … 11 GHz, IP68
Overvoltage protection
Overvoltage protection
Lightning protector
6GK5798-2LP00-2AA6 Lightning protector LP798-1N, for the antennas ANT790 and ANT890, for N-Connect
connectors, N-Connect/N-Connect female/female connector, suitable for 0 ... 6 GHz,
IP68, also suitable for DC feed-in via the antenna cable
