LEDs, connectors, buttons, card slots
2.4 The "SET" button
LOGO! CMR2020, LOGO! CMR2040
32 Operating Instructions, 10/2016, C79000-G8976-C356-03
Connection to the local area network
Port X1P1 of the CMR is intended for LAN connection to the local network/PC and to
connect to the BM. The IP address of port X1P1 can be configured.
Connection to the mobile wireless network and GPS
For the wireless connection, the CMR has two SMA sockets:
● SMA socket XR02 for the mobile wireless network
● SMA socket XR01 for GPS reception
For the connection of I/O elements, the following inputs and outputs are available:
● Digital inputs
I1 + I2
● Digital outputs
Q1 + Q2
The "SET" button
Operator control/connector and display elements of the CMR
The SET button has different functions depending on how long you hold it pressed.
Press briefly (up to 5 s)
Keep pressed for 5 to 10 sec-
onds
Shutting down the device to a safe status
Result:
• All LED indicators are off.
• The device can be disconnected from the power supply.
The CMR can no longer be woken out of the shutdown status. To restart you need to
turn the power supply off and on again.
Keep pressed for longer than
10 seconds
Reset to factory settings
For information on the effects, refer to the section Resetting to factory settings
