LEDs, connectors, buttons, card slots
2.3 Interfaces
LOGO! CMR2020, LOGO! CMR2040
Operating Instructions, 10/2016, C79000-G8976-C356-03
31
F
Error
OFF
No error
ON
Error, see also section Disruptions and their possible causes
(Page 134).
Flashing
Duplicate IP address detected. Ethernet interface unreacha-
ble.
I1
Input 1
Off
U < 5 V
Lit green
U > 8.5 V
I2
Input 2
Off
U < 5 V
Lit green
U > 8.5 V
Q1
Output 1
Off
No voltage at output
Lit green
Supply voltage at output
Q2
Output 2
Off
No voltage at output
Lit green
Supply voltage at output
You will find information on connecting the interfaces and connectors in the section
Connecting up the device (Page 39).
You will detailed data of the interfaces and connectors in the section Technical specifications
(Page 141).
Connecting to the power supply
For connecting to the power supply terminal X10 is available.
