Application and functions
1.4 Application examples
LOGO! CMR2020, LOGO! CMR2040
22 Operating Instructions, 10/2016, C79000-G8976-C356-03
You can operate the CMR without a BM being connected. If the CMR is connected to a
mobile wireless antenna, the following functions are available:
● Sending an SMS message or e-mail due to a signal at the input of the CMR
● Receiving an SMS message:
– Setting an output of the CMR
– Requesting and SMS message with status information of the CMR
Using the WBM of the CMR, you can configure events such as changing of input signals as
well as actions. The actions are triggered when configurable events occur.
● Installation, connecting up and commissioning have been completed.
● The antenna for receipt of mobile wireless is connected.
To configure access via the mobile wireless network, follow the steps below:
1. First establish a configuration connection between the CMR and a connected PC. To do
this, use an Ethernet patch cable, see Establishing a connection to the CMR (Page 63)
2. Configure the mobile wireless connection, see Mobile wireless settings (Page 87).
3. Configure the device using the WBM.
Mobile wireless communication by SMS / e-mail with LOGO! BM
Figure 1-3 Mobile wireless communication with LOGO! BM
