Uses and properties of the TIM
1.5 DNP3 device attributes of the TIM
TIM DNP3
22 System Manual, 12/2015, C79000-G8976-C253-04
Return value of the DNP3 TIM
Accuracy of the TIM time stamp
218 Time for which the time stamp accuracy can be
maintained following synchronization.
600 s
Support of analog output events
Not supported (negative acknowledgment)
220 Max. index of the analog outputs According to the configuration
Support of binary output events
Not supported (negative acknowledgment)
Max. index of the binary outputs
According to the configuration
Support of frozen counter events
Support of frozen counters
Support of counter events
Max. index of the counters
According to the configuration
Support of frozen analog inputs
Not supported (negative acknowledgment)
Max. index of the analog inputs
According to the configuration
Support of double bit inputs
Not supported (negative acknowledgment)
Max. index of double bit inputs
Number of double bit inputs
Support of event messages with binary inputs
Max. index of the binary inputs
According to the configuration
239 Number of binary inputs Max. index +1
240 Max. size of the application layer fragments in send
direction (station → master station)
2048 bytes
241 Max. size of the application layer fragments in re-
ceive direction (master station → station)
2048 bytes
Not defined in the protocol specification
User-specified string (location)
Not supported (negative acknowledgment)
User-specified string (code)
User-specified string (name)
Not supported (negative acknowledgment)
Not supported (negative acknowledgment)
249 DNP3 implementation level Value of the configured conformity level of the DNP3
