The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
232 System Manual, 12/2015, C79000-G8976-C253-04
Table 6- 10 Range of values of the MODBUS read status
Code
Meaning
0x7002
Job executed without errors
0x8000 Job executed with error
0x8001 Illegal Function
After this error has occurred, the read job is blocked until the TIM restarts and is no
longer sent to the slave.
0x8002
Illegal Data Address
0x8003
Illegal Data Value
0x8004
Slave Device Failure
0x8005
Message transferred but slave device busy with a different process (Acknowledge)
0x8006 Slave Device Busy with other process. The query should be repeated by the mas-
ter.
0x8008
Memory Parity Error
0x800C
Wrong CRC check value in the response message of the slave
0x800D
Wrong net data in the response message of the slave
0x800E Wrong slave address in the response message of the slave
After this error has occurred, the read job is blocked until the TIM restarts and is no
longer sent to the slave.
0x800F
Wrong function code in the response message of the slave
0x8010
No response (send timeout exceeded)
