Siemens SINUMERIK 828D Service Manual

Service cases - hardware
4.14 Sensor Modules Cabinet
Hardware and Software
Service Manual, 03/2011, 6FC5397-5DP40-0BA0
185
4.14.7 This is how you remove an SMC30
Overview
The activities that must be taken into account when replacing an SMC30 are subsequently
described.
If an SMC30 has a hardware defect, then it must be replaced by an identical module.
Preconditions:
● The module is defective and must be replaced.
● The control cabinet is in a no-voltage condition, all of the connectors and cables are
labeled.
Removing
6ZLYHOWKHPRGXOHWRWKHIURQW
0RXQWLQJVOLGH
5RWDWHDVFUHZGULYHUZLWKDZLGHEODGHWRPP
LQWKHVORWRIWKHPRXQWLQJVOLGHWKURXJKrRU
DOWHUQDWLYHO\SUHVVWKHOXJGRZQZDUGV

Figure 4-41 SMC30 removal
