Service cases - hardware
4.17 Hub Modules
Hardware and Software
204 Service Manual, 03/2011, 6FC5397-5DP40-0BA0
4.17.4 This is how you install a DMC20
Installing
Procedure:
1. Place the components on the mounting rail.
2. Then, swivel the components on the mounting rail so that the mounting catches click into
place at the rear.
3. Slide the components along the mounting rail to either the left or right up to their final
position.
4. Screw on the protective conductor connection.
5. Screw on the encoder connecting cable to X520.
6. Insert the DRIVE-CLiQ cable at X500 – X505.
7. Insert connector X524 for the electronics power supply.
CAUTION
The 50 mm clearances above and below the components must be observed.
