Siemens SINUMERIK 828D Service Manual

Service cases - hardware
4.17 Hub Modules
Hardware and Software
Service Manual, 03/2011, 6FC5397-5DP40-0BA0
205
4.17.5 DME20 connections
Connections
The component has degree of protection IP67 and is especially suitable for applications
which require DRIVE-CLiQ nodes to be removed in groups, without interrupting the DRIVE-
CLiQ line and therefore the data exchange.
;
;
;
;
;
;
;
;
Figure 4-51 DME20 connections
