Functions
2.7 Teleprotection for Distance Protection (optional)
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
215
2.7.15 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under Additional Settings.
2.7.16 Information List
Addr. Parameter Setting Options Default Setting Comments
2101 FCT Telep. Dis. ON
OFF
ON Teleprotection for Distance pro-
tection
2102 Type of Line Two Terminals
Three terminals
Two Terminals Type of Line
2103A Send Prolong. 0.00 .. 30.00 sec 0.05 sec Time for send signal prolongation
2107A Delay for alarm 0.00 .. 30.00 sec 10.00 sec Time Delay for Alarm
2108 Release Delay 0.000 .. 30.000 sec 0.000 sec Time Delay for release after
pickup
2109A TrBlk Wait Time 0.00 .. 30.00 sec; ∞ 0.04 sec Transient Block.: Duration exter-
nal flt.
2110A TrBlk BlockTime 0.00 .. 30.00 sec 0.05 sec Transient Block.: Blk.T. after ext.
flt.
2112A DIS TRANSBLK EF YES
NO
YES DIS transient block by EF
2113 Mem.rec.sig. YES
NO
NO Memorize receive signal
No. Information Type of In-
formation
Comments
4001 >Dis.Telep. ON SP >Distance Teleprotection ON
4002 >Dis.Telep.OFF SP >Distance Teleprotection OFF
4003 >Dis.Telep. Blk SP >Distance Teleprotection BLOCK
4005 >Dis.RecFail SP >Dist. teleprotection: Carrier faulty
4006 >DisTel Rec.Ch1 SP >Dis.Tele. Carrier RECEPTION Channel 1
4007 >Dis.T.RecCh1L1 SP >Dis.Tele.Carrier RECEPTION Channel 1,L1
4008 >Dis.T.RecCh1L2 SP >Dis.Tele.Carrier RECEPTION Channel 1,L2
4009 >Dis.T.RecCh1L3 SP >Dis.Tele.Carrier RECEPTION Channel 1,L3
4010 >Dis.T.Rec.Ch2 SP >Dis.Tele. Carrier RECEPTION Channel 2
4030 >Dis.T.UB ub 1 SP >Dis.Tele. Unblocking: UNBLOCK Channel 1
4031 >Dis.T.UB bl 1 SP >Dis.Tele. Unblocking: BLOCK Channel 1
4032 >Dis.T.UB ub1L1 SP >Dis.Tele. Unblocking: UNBLOCK Ch. 1, L1
4033 >Dis.T.UB ub1L2 SP >Dis.Tele. Unblocking: UNBLOCK Ch. 1, L2
4034 >Dis.T.UB ub1L3 SP >Dis.Tele. Unblocking: UNBLOCK Ch. 1, L3
4035 >Dis.T.UB ub 2 SP >Dis.Tele. Unblocking: UNBLOCK Channel 2
4036 >Dis.T.UB bl 2 SP >Dis.Tele. Unblocking: BLOCK Channel 2
4040 >Dis.T.BlkEcho SP >Dis.Tele. BLOCK Echo Signal
4050 Dis.T.on/off BI IntSP Dis. Teleprotection ON/OFF via BI
4052 Dis.Telep. OFF OUT Dis. Teleprotection is switched OFF
4054 Dis.T.Carr.rec. OUT Dis. Telep. Carrier signal received
