Functions
2.24 Monitoring Functions
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
435
2.24.1.6 Setting Notes
General
The sensitivity of the measured value monitoring can be changed. Experiential values set ex works are ade-
quate in most cases. If particularly high operational asymmetries of the currents and/or voltages are expected,
or if one or more monitoring functions pick up sporadically during normal operation, the sensitivity settings
should be made less sensitve..
The measurement supervision can be switched ON or OFF in address 2901 MEASURE. SUPERV.
Symmetry monitoring
Address 2902 BALANCE U-LIMIT determines the limit voltage (phase-to-phase), above which the voltage
symmetry monitoring is effective. Address 2903 BAL. FACTOR U is the associated balance factor, i.e. the
gradient of the balance characteristic. The indication „Fail U balance“ (no. 167) can be delayed at address
2908 T BAL. U LIMIT. These settings can only be changed using DIGSI at Additional Settings.
Address 2904 BALANCE I LIMIT determines the limit current above which the current symmetry monitoring
is effective. Address 2905 BAL. FACTOR I is the associated balance factor, i.e. the gradient of the balance
characteristic. The indication „Fail I balance“ (no. 163) can be delayed at address 2909 T BAL. I
LIMIT. These settings can only be changed using DIGSI at Additional Settings.
Sum monitoring
Address 2906 ΣI THRESHOLD determines the limit current above which the current sum monitoring is activat-
ed (absolute portion, only relative to I
N
). The relative portion (relative to the maximum phase current) for acti-
vating the current sum monitoring is set at address 2907 ΣI FACTOR. These settings can only be changed
using DIGSI at Additional Settings.
Note
Current sum supervision can operate properly only when the ground current of the protected line is connected
to the fourth current measuring input (I
4
). The I
4
transformer must have been configured with parameter I4
transformer (address 220) as . Furthermore, the fourth current measuring must be designed as normal I
4
transformer. With a sensitive transformer type, the current sum supervision is not active.
Broken wire monitoring
The broken wire monitoring is enabled or disabled via the parameter 2931 BROKEN WIRE. The differential pro-
tection function is only blocked with the setting ON. By means of the setting Alarm only, a broken wire can
be signalled; the protection functions are not blocked.
In case of a 1-1/2 circuit breaker arrangement, the parameter 208 1-1/2 CB is to be set to YES. Parameter
2935 ΔI min indicates the minimum difference for this circuit breaker arrangement by which the current would
decrease in case of a wire break.
