Siemens SIPROTEC User Manual

Appendix
A.4 Default Settings
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
675
A.4.2 Binary Input
Table A-2 Binary input presettings for all devices and ordering variants
Binary Input Allocated Func-
tion
Function No. Description
BI1 >Reset LED 5 >Reset LED
BI2 >Manual Close 356 >Manual close signal
BI3 no presetting - -
BI4 >BLOCK O/C I>> 7104 >BLOCK Backup OverCurrent I>>
>BLOCK O/C I> 7105 >BLOCK Backup OverCurrent I>
>BLOCK O/C Ip 7106 >BLOCK Backup OverCurrent Ip
>BLOCK O/C Ie>> 7107 >BLOCK Backup OverCurrent Ie>>
>BLOCK O/C Ie> 7108 >BLOCK Backup OverCurrent Ie>
>BLOCK O/C Iep 7109 >BLOCK Backup OverCurrent Iep
>BLOCK I-STUB 7130 >BLOCK I-STUB
>BLOCK O/CIe>>> 7132 >BLOCK Backup OverCurrent Ie>>>
BI5 no presetting - -
BI6 >CB1 Ready 371 >CB1 READY (for AR,CB-Test)
BI7 >Remote CMD 1 3541 >Remote Command 1 signal input
