Functions
2.26 Additional Functions
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
484
2.26.10.1Limit value monitoring
Set points can be set for the following measured and metered values:
• IL1dmd>: Exceeding a preset maximum average value in Phase L1.
• IL2dmd>: Exceeding a preset maximum average value in Phase L2.
• IL3dmd>: Exceeding a preset maximum average value in Phase L3.
• I1dmd>: Exceeding a preset maximum average value of the positive sequence system currents.
• |Pdmd|> : Exceeding a preset maximum average active power.
• |Qdmd|>: Exceeding a preset maximum average reactive power.
• |Sdmd|> : Exceeding a preset maximum average value of the apparent power.
•|cosϕ|< falling below a preset power factor.
2.26.10.2Setting Notes
Set Points for Measured Values
The settings are entered under MEASUREMENT in the sub-menu SET POINTS (MV) (MV) by overwriting the
existing values.
2.26.10.3Information List
No. Information Type of In-
formation
Comments
- IL1dmd> LV Upper setting limit for IL1dmd
- IL2dmd> LV Upper setting limit for IL2dmd
- IL3dmd> LV Upper setting limit for IL3dmd
- I1dmd> LV Upper setting limit for I1dmd
- |Pdmd|> LV Upper setting limit for Pdmd
- |Qdmd|> LV Upper setting limit for Qdmd
- Sdmd> LV Upper setting limit for Sdmd
- PF< LV Lower setting limit for Power Factor
273 SP. IL1 dmd> OUT Set Point Phase L1 dmd>
274 SP. IL2 dmd> OUT Set Point Phase L2 dmd>
275 SP. IL3 dmd> OUT Set Point Phase L3 dmd>
276 SP. I1dmd> OUT Set Point positive sequence I1dmd>
277 SP. |Pdmd|> OUT Set Point |Pdmd|>
278 SP. |Qdmd|> OUT Set Point |Qdmd|>
279 SP. |Sdmd|> OUT Set Point |Sdmd|>
285 cosϕ alarm OUT Power factor alarm
