Siemens SIPROTEC User Manual

Functions
2.13 Transmission of Binary Commands and Messages
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
288
2.13.2 Information List
No. Information Type of In-
formation
Comments
3541 >Remote CMD 1 SP >Remote Command 1 signal input
3542 >Remote CMD 2 SP >Remote Command 2 signal input
3543 >Remote CMD 3 SP >Remote Command 3 signal input
3544 >Remote CMD 4 SP >Remote Command 4 signal input
3545 Remote CMD1 rec OUT Remote Command 1 received
3546 Remote CMD2 rec OUT Remote Command 2 received
3547 Remote CMD3 rec OUT Remote Command 3 received
3548 Remote CMD4 rec OUT Remote Command 4 received
3549 >Rem. Signal 1 SP >Remote Signal 1 input
3550 >Rem.Signal 2 SP >Remote Signal 2 input
3551 >Rem.Signal 3 SP >Remote Signal 3 input
3552 >Rem.Signal 4 SP >Remote Signal 4 input
3553 >Rem.Signal 5 SP >Remote Signal 5 input
3554 >Rem.Signal 6 SP >Remote Signal 6 input
3555 >Rem.Signal 7 SP >Remote Signal 7 input
3556 >Rem.Signal 8 SP >Remote Signal 8 input
3557 >Rem.Signal 9 SP >Remote Signal 9 input
3558 >Rem.Signal10 SP >Remote Signal 10 input
3559 >Rem.Signal11 SP >Remote Signal 11 input
3560 >Rem.Signal12 SP >Remote Signal 12 input
3561 >Rem.Signal13 SP >Remote Signal 13 input
3562 >Rem.Signal14 SP >Remote Signal 14 input
3563 >Rem.Signal15 SP >Remote Signal 15 input
3564 >Rem.Signal16 SP >Remote Signal 16 input
3565 >Rem.Signal17 SP >Remote Signal 17 input
3566 >Rem.Signal18 SP >Remote Signal 18 input
3567 >Rem.Signal19 SP >Remote Signal 19 input
3568 >Rem.Signal20 SP >Remote Signal 20 input
3569 >Rem.Signal21 SP >Remote Signal 21 input
3570 >Rem.Signal22 SP >Remote Signal 22 input
3571 >Rem.Signal23 SP >Remote Signal 23 input
3572 >Rem.Signal24 SP >Remote Signal 24 input
3573 Rem.Sig 1recv OUT Remote signal 1 received
3574 Rem.Sig 2recv OUT Remote signal 2 received
3575 Rem.Sig 3recv OUT Remote signal 3 received
3576 Rem.Sig 4recv OUT Remote signal 4 received
3577 Rem.Sig 5recv OUT Remote signal 5 received
3578 Rem.Sig 6recv OUT Remote signal 6 received
3579 Rem.Sig 7recv OUT Remote signal 7 received
3580 Rem.Sig 8recv OUT Remote signal 8 received
3581 Rem.Sig 9recv OUT Remote signal 9 received
3582 Rem.Sig10recv OUT Remote signal 10 received
3583 Rem.Sig11recv OUT Remote signal 11 received
3584 Rem.Sig12recv OUT Remote signal 12 received
