2.19 Undervoltage and Overvoltage Protection (optional)
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
378
2.19.5 Information List
3778 CURR.SUP.U1< ON
OFF
ON Current supervision (U1)
3779A U1<(<) RESET 1.01 .. 1.20 1.05 U1<(<) Reset ratio
No. Information Type of In-
formation
Comments
234.2100 U<, U> blk IntSP U<, U> blocked via operation
10201 >Uph-e>(>) BLK SP >BLOCK Uph-e>(>) Overvolt. (phase-earth)
10202 >Uph-ph>(>) BLK SP >BLOCK Uph-ph>(>) Overvolt (phase-phase)
10203 >3U0>(>) BLK SP >BLOCK 3U0>(>) Overvolt. (zero sequence)
10204 >U1>(>) BLK SP >BLOCK U1>(>) Overvolt. (positive seq.)
10205 >U2>(>) BLK SP >BLOCK U2>(>) Overvolt. (negative seq.)
10206 >Uph-e<(<) BLK SP >BLOCK Uph-e<(<) Undervolt (phase-earth)
10207 >Uphph<(<) BLK SP >BLOCK Uphph<(<) Undervolt (phase-phase)
10208 >U1<(<) BLK SP >BLOCK U1<(<) Undervolt (positive seq.)
10215 Uph-e>(>) OFF OUT Uph-e>(>) Overvolt. is switched OFF
10216 Uph-e>(>) BLK OUT Uph-e>(>) Overvolt. is BLOCKED
10217 Uph-ph>(>) OFF OUT Uph-ph>(>) Overvolt. is switched OFF
10218 Uph-ph>(>) BLK OUT Uph-ph>(>) Overvolt. is BLOCKED
10219 3U0>(>) OFF OUT 3U0>(>) Overvolt. is switched OFF
10220 3U0>(>) BLK OUT 3U0>(>) Overvolt. is BLOCKED
10221 U1>(>) OFF OUT U1>(>) Overvolt. is switched OFF
10222 U1>(>) BLK OUT U1>(>) Overvolt. is BLOCKED
10223 U2>(>) OFF OUT U2>(>) Overvolt. is switched OFF
10224 U2>(>) BLK OUT U2>(>) Overvolt. is BLOCKED
10225 Uph-e<(<) OFF OUT Uph-e<(<) Undervolt. is switched OFF
10226 Uph-e<(<) BLK OUT Uph-e<(<) Undervolt. is BLOCKED
10227 Uph-ph<(<) OFF OUT Uph-ph<(<) Undervolt. is switched OFF
10228 Uph-ph<(<) BLK OUT Uphph<(<) Undervolt. is BLOCKED
10229 U1<(<) OFF OUT U1<(<) Undervolt. is switched OFF
10230 U1<(<) BLK OUT U1<(<) Undervolt. is BLOCKED
10231 U</> ACTIVE OUT Over-/Under-Voltage protection is ACTIVE
10240 Uph-e> Pickup OUT Uph-e> Pickup
10241 Uph-e>> Pickup OUT Uph-e>> Pickup
10242 Uph-e>(>) PU L1 OUT Uph-e>(>) Pickup L1
10243 Uph-e>(>) PU L2 OUT Uph-e>(>) Pickup L2
10244 Uph-e>(>) PU L3 OUT Uph-e>(>) Pickup L3
10245 Uph-e> TimeOut OUT Uph-e> TimeOut
10246 Uph-e>> TimeOut OUT Uph-e>> TimeOut
10247 Uph-e>(>) TRIP OUT Uph-e>(>) TRIP command
10248 Uph-e> PU L1 OUT Uph-e> Pickup L1
10249 Uph-e> PU L2 OUT Uph-e> Pickup L2
10250 Uph-e> PU L3 OUT Uph-e> Pickup L3
