Siemens SIPROTEC User Manual

Functions
2.17 Automatic Reclosure Function (optional)
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
346
2.17.4 Information List
No. Information Type of In-
formation
Comments
127 AR ON/OFF IntSP Auto Reclose ON/OFF (via system port)
2701 >AR on SP >AR: Switch on auto-reclose function
2702 >AR off SP >AR: Switch off auto-reclose function
2703 >AR block SP >AR: Block auto-reclose function
2711 >AR Start SP >External start of internal Auto reclose
2712 >Trip L1 AR SP >AR: External trip L1 for AR start
2713 >Trip L2 AR SP >AR: External trip L2 for AR start
2714 >Trip L3 AR SP >AR: External trip L3 for AR start
2715 >Trip 1pole AR SP >AR: External 1pole trip for AR start
2716 >Trip 3pole AR SP >AR: External 3pole trip for AR start
2727 >AR RemoteClose SP >AR: Remote Close signal
2731 >Sync.release SP >AR: Sync. release from ext. sync.-check
2737 >BLOCK 1pole AR SP >AR: Block 1pole AR-cycle
2738 >BLOCK 3pole AR SP >AR: Block 3pole AR-cycle
2739 >BLK 1phase AR SP >AR: Block 1phase-fault AR-cycle
2740 >BLK 2phase AR SP >AR: Block 2phase-fault AR-cycle
2741 >BLK 3phase AR SP >AR: Block 3phase-fault AR-cycle
2742 >BLK 1.AR-cycle SP >AR: Block 1st AR-cycle
2743 >BLK 2.AR-cycle SP >AR: Block 2nd AR-cycle
2744 >BLK 3.AR-cycle SP >AR: Block 3rd AR-cycle
2745 >BLK 4.-n. AR SP >AR: Block 4th and higher AR-cycles
2746 >Trip for AR SP >AR: External Trip for AR start
2747 >Pickup L1 AR SP >AR: External pickup L1 for AR start
2748 >Pickup L2 AR SP >AR: External pickup L2 for AR start
2749 >Pickup L3 AR SP >AR: External pickup L3 for AR start
2750 >Pickup 1ph AR SP >AR: External pickup 1phase for AR start
2751 >Pickup 2ph AR SP >AR: External pickup 2phase for AR start
2752 >Pickup 3ph AR SP >AR: External pickup 3phase for AR start
2781 AR off OUT AR: Auto-reclose is switched off
2782 AR on IntSP AR: Auto-reclose is switched on
2783 AR is blocked OUT AR: Auto-reclose is blocked
2784 AR not ready OUT AR: Auto-reclose is not ready
2787 CB not ready OUT AR: Circuit breaker not ready
2788 AR T-CBreadyExp OUT AR: CB ready monitoring window expired
2796 AR on/off BI IntSP AR: Auto-reclose ON/OFF via BI
2801 AR in progress OUT AR: Auto-reclose in progress
2809 AR T-Start Exp OUT AR: Start-signal monitoring time expired
2810 AR TdeadMax Exp OUT AR: Maximum dead time expired
2818 AR evolving Flt OUT AR: Evolving fault recognition
2820 AR Program1pole OUT AR is set to operate after 1p trip only
2821 AR Td. evol.Flt OUT AR dead time after evolving fault
2839 AR Tdead 1pTrip OUT AR dead time after 1pole trip running
2840 AR Tdead 3pTrip OUT AR dead time after 3pole trip running
2841 AR Tdead 1pFlt OUT AR dead time after 1phase fault running
