Siemens SIPROTEC User Manual

Functions
2.1 General
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
68
2.1.4.2 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under Additional Settings.
The table indicates region-specific presettings. Column C (configuration) indicates the corresponding second-
ary nominal current of the current transformer.
Addr. Parameter C Setting Options Default Setting Comments
1103 FullScaleVolt. 0.4 .. 1200.0 kV 400.0 kV Measurement: Full Scale
Voltage (100%)
1104 FullScaleCurr. 10 .. 10000 A 1000 A Measurement: Full Scale
Current (100%)
1105 Line Angle 10 .. 89 ° 85 ° Line Angle
1106 OPERATION POWER 0.2 .. 5000.0 MVA 692.8 MVA Operational power of pro-
tection zone
1107 P,Q sign not reversed
reversed
not reversed P,Q operational measured
values sign
1111 x' 1A 0.0050 .. 9.5000 Ω/km 0.1500 Ω/km x' - Line Reactance per
length unit
5A 0.0010 .. 1.9000 Ω/km 0.0300 Ω/km
1111 x' 1A 0.0050 .. 15.0000 Ω/mi 0.2420 Ω/mi x' - Line Reactance per
length unit
5A 0.0010 .. 3.0000 Ω/mi 0.0484 Ω/mi
1112 c' 1A 0.000 .. 100.000 µF/km 0.010 µF/km c' - capacit. per unit line
len. µF/km
5A 0.000 .. 500.000 µF/km 0.050 µF/km
1112 c' 1A 0.000 .. 160.000 µF/mi 0.016 µF/mi c' - capacit. per unit line
len. µF/mile
5A 0.000 .. 800.000 µF/mi 0.080 µF/mi
1113 Line Length 0.1 .. 1000.0 km 100.0 km Line Length
1113 Line Length 0.1 .. 650.0 Miles 62.1 Miles Line Length
1114 Tot.Line Length 0.1 .. 1000.0 km 100.0 km Total Line Length
1114 Tot.Line Length 0.1 .. 650.0 Miles 62.1 Miles Total Line Length
1116 RE/RL(Z1) -0.33 .. 10.00 1.00 Zero seq. comp. factor
RE/RL for Z1
1117 XE/XL(Z1) -0.33 .. 10.00 1.00 Zero seq. comp. factor
XE/XL for Z1
1118 RE/RL(> Z1) -0.33 .. 10.00 1.00 Zero seq. comp.factor
RE/RL(> Z1)
1119 XE/XL(> Z1) -0.33 .. 10.00 1.00 Zero seq. comp.factor
XE/XL(> Z1)
1120 K0 (Z1) 0.000 .. 4.000 1.000 Zero seq. comp. factor K0
for zone Z1
1121 Angle K0(Z1) -180.00 .. 180.00 ° 0.00 ° Zero seq. comp. angle for
zone Z1
1122 K0 (> Z1) 0.000 .. 4.000 1.000 Zero seq.comp.factor
K0,higher zones >Z1
1123 Angle K0(> Z1) -180.00 .. 180.00 ° 0.00 ° Zero seq. comp. angle,
higher zones >Z1
