2.2 Protection Data Interfaces and Protection Data Topology
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
92
2.2.4.2 Settings
2.2.4.3 Information List
Addr. Parameter Setting Options Default Setting Comments
4701 ID OF RELAY 1 1 .. 65534 1 Identification number of relay 1
4702 ID OF RELAY 2 1 .. 65534 2 Identification number of relay 2
4703 ID OF RELAY 3 1 .. 65534 3 Identification number of relay 3
4704 ID OF RELAY 4 1 .. 65534 4 Identification number of relay 4
4705 ID OF RELAY 5 1 .. 65534 5 Identification number of relay 5
4706 ID OF RELAY 6 1 .. 65534 6 Identification number of relay 6
4710 LOCAL RELAY relay 1
relay 2
relay 3
relay 4
relay 5
relay 6
relay 1 Local relay is
No. Information Type of In-
formation
Comments
3452 >Logout ON SP > Logout state ON
3453 >Logout OFF SP > Logout state OFF
3457 Ringtopology OUT System operates in a closed Ringtopology
3458 Chaintopology OUT System operates in a open Chaintopology
3459 Logout ON/off IntSP Logout state ON/OFF
3460 Logout ON/offBI IntSP Logout state ON/OFF via BI
3464 Topol complete OUT Communication topology is complete
3475 Rel1Logout IntSP Relay 1 in Logout state
3476 Rel2Logout IntSP Relay 2 in Logout state
3477 Rel3Logout IntSP Relay 3 in Logout state
3478 Rel4Logout IntSP Relay 4 in Logout state
3479 Rel5Logout IntSP Relay 5 in Logout state
3480 Rel6Logout IntSP Relay 6 in Logout state
3484 Logout IntSP Local activation of Logout state
3487 Equal IDs OUT Equal IDs in constellation
3491 Rel1 Login OUT Relay 1 in Login state
3492 Rel2 Login OUT Relay 2 in Login state
3493 Rel3 Login OUT Relay 3 in Login state
3494 Rel4 Login OUT Relay 4 in Login state
3495 Rel5 Login OUT Relay 5 in Login state
3496 Rel6 Login OUT Relay 6 in Login state
