Functions
2.26 Additional Functions
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
471
Number of automatic reclosing commands
If the device is equipped with the integrated automatic reclosure, the automatic close commands are also
counted, separately for reclosure after 1-pole tripping, after 3-pole tripping as well as separately for the first re-
closure cycle and other reclosure cycles.
Interrupted currents
Furthermore, for each trip command the interrupted current for each pole is acquired, output in the trip log and
accumulated in a memory. The maximum interrupted current is stored as well. The indicated measured values
are indicated in primary values.
Transmission statistics
In 7SD5 the protection communication is registered in statistics. The delay times of the information between
the devices via interfaces (run and return) are measured steadily. The values are kept stored in the Statistics
folder. The availability of the transmission media is also reported. The availability is indicated in % / min and
% / h. This enables an evaluation of the transmission quality.
If GPS synchronization is configured, the transmission times for each direction and each protection data inter-
face are regularly measured and indicated as long as GPS synchronization is intact.
2.26.3.2 Information List
No. Information Type of In-
formation
Comments
1000 # TRIPs= VI Number of breaker TRIP commands
1001 TripNo L1= VI Number of breaker TRIP commands L1
1002 TripNo L2= VI Number of breaker TRIP commands L2
1003 TripNo L3= VI Number of breaker TRIP commands L3
1027 Σ IL1 = VI Accumulation of interrupted current L1
1028 Σ IL2 = VI Accumulation of interrupted current L2
1029 Σ IL3 = VI Accumulation of interrupted current L3
1030 Max IL1 = VI Max. fault current Phase L1
1031 Max IL2 = VI Max. fault current Phase L2
1032 Max IL3 = VI Max. fault current Phase L3
2895 AR #Close1./1p= VI No. of 1st AR-cycle CLOSE commands,1pole
2896 AR #Close1./3p= VI No. of 1st AR-cycle CLOSE commands,3pole
2897 AR #Close2./1p= VI No. of higher AR-cycle CLOSE commands,1p
2898 AR #Close2./3p= VI No. of higher AR-cycle CLOSE commands,3p
7751 PI1 TD MV Prot.Interface 1:Transmission delay
7752 PI2 TD MV Prot.Interface 2:Transmission delay
7753 PI1A/m MV Prot.Interface 1: Availability per min.
7754 PI1A/h MV Prot.Interface 1: Availability per hour
7755 PI2A/m MV Prot.Interface 2: Availability per min.
7756 PI2A/h MV Prot.Interface 2: Availability per hour
7875 PI1 TD R MV Prot.Interface 1:Transmission delay rec.
7876 PI1 TD S MV Prot.Interface 1:Transmission delay send
7877 PI2 TD R MV Prot.Interface 2:Transmission delay rec.
7878 PI2 TD S MV Prot.Interface 2:Transmission delay send
