Functions
2.8 Earth Fault Protection in Earthed Systems (optional)
SIPROTEC, 7SD5, Manual
C53000-G1176-C169-5, Release date 02.2011
248
2.8.4 Information List
No. Information Type of In-
formation
Comments
1305 >EF BLK 3I0>>> SP >Earth Fault O/C Block 3I0>>>
1307 >EF BLOCK 3I0>> SP >Earth Fault O/C Block 3I0>>
1308 >EF BLOCK 3I0> SP >Earth Fault O/C Block 3I0>
1309 >EF BLOCK 3I0p SP >Earth Fault O/C Block 3I0p
1310 >EF InstTRIP SP >Earth Fault O/C Instantaneous trip
1331 E/F Prot. OFF OUT Earth fault protection is switched OFF
1332 E/F BLOCK OUT Earth fault protection is BLOCKED
1333 E/F ACTIVE OUT Earth fault protection is ACTIVE
1335 EF TRIP BLOCK OUT Earth fault protection Trip is blocked
1336 E/F L1 selec. OUT E/F phase selector L1 selected
1337 E/F L2 selec. OUT E/F phase selector L2 selected
1338 E/F L3 selec. OUT E/F phase selector L3 selected
1345 EF Pickup OUT Earth fault protection PICKED UP
1354 EF 3I0>>>Pickup OUT E/F 3I0>>> PICKED UP
1355 EF 3I0>> Pickup OUT E/F 3I0>> PICKED UP
1356 EF 3I0> Pickup OUT E/F 3I0> PICKED UP
1357 EF 3I0p Pickup OUT E/F 3I0p PICKED UP
1358 EF forward OUT E/F picked up FORWARD
1359 EF reverse OUT E/F picked up REVERSE
1361 EF Trip OUT E/F General TRIP command
1362 E/F Trip L1 OUT Earth fault protection: Trip 1pole L1
1363 E/F Trip L2 OUT Earth fault protection: Trip 1pole L2
1364 E/F Trip L3 OUT Earth fault protection: Trip 1pole L3
1365 E/F Trip 3p OUT Earth fault protection: Trip 3pole
1366 EF 3I0>>> TRIP OUT E/F 3I0>>> TRIP
1367 EF 3I0>> TRIP OUT E/F 3I0>> TRIP
1368 EF 3I0> TRIP OUT E/F 3I0> TRIP
1369 EF 3I0p TRIP OUT E/F 3I0p TRIP
1370 EF InrushPU OUT E/F Inrush picked up
14080 E/F 3I0>>>BLOCK OUT E/F 3I0>>> is blocked
14081 E/F 3I0>> BLOCK OUT E/F 3I0>> is blocked
14082 E/F 3I0> BLOCK OUT E/F 3I0> is blocked
14083 E/F 3I0p BLOCK OUT E/F 3I0p is blocked
