ATYSp - 542001E - SOCOMEC
Dec.
Address
Hex.
Address
Words
count
Description Unit
50788 C664 2 Partial Negative Reactive Energy : Er - kvarh
AnnexeII-3.Metrologynotaffectedbycurrentandvoltagetransformers
Function 3 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
51281 C851 1 Phase to Phase Voltage: U12 (load) V/100
51282 C852 1 Phase to Phase Voltage: U23 (load) V/100
51283 C853 1 Phase to Phase Voltage: U31 (load) V/100
51284 C854 1 Simple voltage: V1 (load) V/100
51285 C855 1 Simple voltage: V2 (load) V/100
51286 C856 1 Simple voltage: V3 (load) V/100
51287 C857 1 Frequency: F Hz/100
51288 C858 1 Current: I1 mA
51289 C859 1 Current: I2 mA
51290 C85A 1 Current: I3 mA
51291 C85B 1 Neutral Current: In mA
51292 C85C 1 ∑ active Power ± : P kW/100 (Signed)
51293 C85D 1 ∑ reactive Power ±: Q kvar/100 (Signed)
51294 C85E 1 ∑ apparent power: S kVA/100
51295 C85F 1 ∑ power factor: -: leading and +: lagging: PF 0,001 (Signed)
51296 C860 1 Active Power phase 1 ±: P1 kW/100 (Signed)
51297 C861 1 Active Power phase 2 ±: P2 kW/100 (Signed)
51298 C862 1 Active Power phase 3 ±: P3 kW/100 (Signed)
51299 C863 1 Reactive Power phase 1 ±: Q1 kvar/100 (Signed)
51300 C864 1 Reactive Power phase 2 ±: Q2 kvar/100 (Signed)
51301 C865 1 Reactive Power phase 3 ±: Q3 kvar/100 (Signed)
51302 C866 1 Apparent power phase 1: S1 kVA/100
51303 C867 1 Apparent power phase 2: S2 kVA/100
51304 C868 1 Apparent power phase 3: S3 kVA/100
51305 C869 1 Power Factor phase 1 -: leading and +: lagging : PF1 0,001 (Signed)
51306 C86A 1 Power Factor phase 2 -: leading and +: lagging : PF2 0,001 (Signed)
51307 C86B 1 Power Factor phase 3 -: leading and +: lagging : PF3 0,001 (Signed)
51311 C86F 1 Total Positive Active Energy (no resetable): Ea+ MWh
51312 C870 1 Total Positive Reactive Energy (no resetable): Er + Mvarh
51313 C871 1 Total Negative Active Energy (no resetable): Ea- MWh
51314 C872 1 Total Negative Reactive Energy (no resetable): Er - Mvarh
AnnexeII-4.Input/Outputstate
Function 3 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
51968 CB00 1 Input count
51969 CB01 1 Bit 0: Input 1 Open or Closed
Bit x: Input x +1 Open or Closed
51970 CB02 1 Output count
51971 CB03 1 Bit 0: Output 1 Open or Closed
Bit x: Output x +1 Open or Closed
