EN
ATYSp - 542001E - SOCOMEC
5.5. ATySpACCESSORIESAVAILABLE
BRIDGINGBARS
To connect switch I & II load terminals together.
VOLTAGESENSINGANDPOWERSUPPLYKIT
Allows voltage sensing and power supply connections from
switch terminals to power supply and control module. Secure
cables tray, no specic cable protection required (fuse type).
TERMINALSHROUDS(125TO630A)
Incoming and outgoing protection against direct contact with
the connection terminals or parts. Cannot be mounted in the
rear position at the same time as the voltage sensing and
power outlet kit or the bridging bars.
Can be mounted top or bottom, in front or in rear position.
TERMINAL SCREENS
Incoming and outgoing protection against direct contact with
the connection terminals or parts.
REMOTE INTERFACES D20
• Remote Display: Allows source supply state and switch
positions to be displayed remotely.
• Remote Control: Allows remote conguration, control and
metering (from front panel) on which the device is mounted.
Typically door mounted or ≤3m away from the ATyS.
DOOR ESCUTCHEON PLATE
An accessory to be xed onto a cabinet door to frame the
controller part of ush mounted ATySp transfer switches.
CURRENT TRANSFORMERS
An extensive range of CT’s is available from SOCOMEC. Refer
to the SOCOMEC general catalogue for details.
COMMUNICATIONCABLE
RJ 45 communication cable (3m long) for use with the D20
remote display/controller or Ethernet modules.
DCPOWERSUPPLY(DC->AC)
Allows a standard 230VAC ATySp to be supplied through a
12/24/48VDC Aux Power supply.
SUPPLEMENTARYAUXILIARYCONTACT(AC)
Pre-breaking and signaling of positions I and II: 1 additional
auxiliary contact NO / NC auxiliary contact in each position.
Included as standard for ratings from 2000 to 3200A. For
Low level AC: please consult SOCOMEC.
KEYLOCKAUTO/MANUALSELECTORSWITCH
The ATySp mode selector switch is delivered with a rotary
handle as standard. This can be replaced with a key lock.
RONISKEYPADLOCKINGACCESSORIES
Locking of the electrical and manual operation by means of
a RONIS EL11AP lock. Possibility of locking in all positions, if
the “Padlocking in the 3 positions” option is ordered.
Not compatible with ush mounting.
PADLOCKINGIN3POSITIONS
Allows locking of the operation in the 3 positions I, 0 and II.
(Factory tted accessory)
CONTROL VOLTAGE TRANSFORMER
Allows a standard 230 V AC device to be supplied with
400VAC.
MOUNTINGSPACERS(125TO630A)
Raises the device’s terminals 10 mm away from the
backplate or frame
OPTIONAL MODULES
Communication modules (3 Types)
Conguration, Monitoring and control of the changeover
switch via Ethernet / Ethernet Gateway (RJ45 connection) or
MODBUS, (2 or 3-wire RS485 link).
Besides communication, the Ethernet module includes
Webserver monitoring integrated in the module. This gives
remote user friendly access (through internet) to ATySp
setting parameters, history of events, metering, engine
exerciser settings without the need for additional software.
Conguration of the ATySp is recommended to be done
using the SOCOMEC Easy Cong software used with a
standard laptop/computer having an RJ45 connection (to
use with the Ethernet module) or a USB connection (used
with a USB/RS485 converter) for MODBUS modules.
Input / Output Extension Module
2 Inputs/2 Outputs on each module with a maximum of 4
modules on each ATySp. (Attn: When used with an Ethernet
module the remaining space available is for 2 I/O modules.
Similarly when used with a Modbus module the remaining
space available is for 3 I/O modules.
4-20mA analogue output module
3I, In, 3V, 3U, F, ± ΣP, ± ΣQ, ΣS
Pulsed output module
2 congurable pulse outputs (type, weight and duration) on
±kWh, ± kvarh and kVAh
Others:
Refer to the end of this instruction manual or the latest
SOCOMEC product catalogue.
(Downloadable from www.socomec.com)
