socomec ATyS s User Manual


EN
ATYSp - 542001E - SOCOMEC
6.1.2. Dimensions:FrameB6&B7(800Ato1600A)
7
F
12.5
=
200
169166
280
250166
V
=
250
AA
12.5
391.5
293
253.5
Z1
YY
48
94
X
M 51.5
J
TTT
1
3
B
AC
2
3
3
4
5
6
U
atys_838_a_1_x_cat
50.5
20
138
214
atys_843_a_1_x_cat
33 8.58.5
50
3310
ø 9
ø 15
svr_077_a_1_x_cat
800 to 1000 A
16 x 11
60
28.5 15.7515.75
28.515
svr_078_b_1_x_cat
1250 A
15
5
5
12.5
25
25
30
30
45
45
90
ø12.5
svr_098_a_1_x_cat
1600 A
1. Padlocking Facility: Locking bracket for up to 3 padlocks of dia. 4 – 8mm
2. Emergency manual operation: Maximum operating radius with an operating angle of 2x 90°
3. Connection and disconnection area
4. Mounting stand off with spacer accessory
5. Phase Barriers
6. Emergency removable handle
7. Flush mounting cutout dimensions for front door
CAUTION
To consider the space required for manual operation and wiring.

Rating(A)
Overall
dimensions
Terminal
screens
Body Switchmounting Connection
B AC F 3p. F 4p. J 3p. J 4p. M 3p. M 4p. T U V X Y Z1 AA
800 370 461 504 584 307 387 255 335 80 50 60.5 47.5 7 66.5 321
1000 370 461 504 584 307 387 255 335 80 50 60.5 47.5 7 66.5 321
1250 370 461 504 584 307 387 255 335 80 60 65 47.5 7 66.5 330
1600 380 531 596 716 399 519 347 467 120 90 44 53 8 67.5 288
All dimensions in mm
