ATYSp - 542001E - SOCOMEC
Dec.
Address
Hex.
Address
Words
count
Description Unit
20489 5009 1 Fault summary
0: None
1: Alarm
2: Fault
20490 500A 1 Alarm/Fault Code
0x0001: Operating factor (Alarm)
0x0002: Neutral position (Alarm)
0x0004: External fault 1 (Fault)
0x0008: External fault 2 (Fault)
0x0010: Alarm 1 (Alarm)
0x0020: Alarm 2 (Alarm)
0x0040: Source 1 rotation (Alarm)
0x0080: Source 2 rotation (Alarm)
0x0100: Source 1 unbalanced 1 (Alarm)
0x0200: Source 2 unbalanced 2 (Alarm)
0x0400: Position 0 (Fault)
0x0800: Position I (Fault)
0x1000: Position II (Fault)
0x2000: Main fault (Fault)
0x4000: Motor fault (Fault)
0x8000: Autoconguration failed (Alarm)
20491 500B 1 Last Switch over cause
0: None
1: Manual
2: Remote controlled
3: Under voltage source 1
4: Under voltage source 2
5: Over voltage source 1
6: Over voltage source 2
7: Under Frequence source 1
8: Under Frequence source 2
9: Over Frequence source 1
10: Over Frequence source 2
11: Unbalance Source 1
12: Unbalance Source 2
13: Rotation Source 1
14: Rotation Source 2
20492 500C 2 Firmware last ash date -
20494 500E 2 Date of rst commissioning -
20496 5010 8 Product identication -
20504 5018 1 Power supply status
0: No network present for DPS
1: Source 1 present for DPS
2: Source 2 present for DPS
3: Sources 1+2 present for DPS
20505 5019 1 Source 1: Phase 1 presence
1: Present
0: Absent
20506 501A 1 Source 1: Phase 2 presence
1: Present
0: Absent
20507 501B 1 Source 1: Phase 3 presence
1: Present
0: Absent
20508 501C 1 Source 2: Phase 1 presence
1: Present
0: Absent
20509 501D 1 Source 2: Phase 2 presence
1: Present
0: Absent
20510 501E 1 Source 2: Phase 3 presence
1: Present
0: Absent
