socomec ATyS s User Manual

113
EN
ATYSp - 542001E - SOCOMEC
AnnexeII-16.Usercommands
Function 6 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
21840 5550 1 Auto conguration request
1: make autocong
21841 5551 1 Settings backup
1: save current settings as user defaults
2: restore user defaults settings
3: restore factory settings
21842 5552 1 Source 1 partial counters erase
0x01: Ea+
0x02: Er+
0x04: Es
0x08: Ea-
0x10: Er-
0x20: Hour counter
21843 5553 1 Source 2 partial counters erase
0x01: Ea+
0x02: Er+
0x04: Es
0x08: Ea-
0x10: Er-
0x20: Hour counter
21844 5554 1 Product user counters erase
0x01: Genset start counter erase
0x02: Genset runtime counter erase
0x04: Secondary source presence counter erase
0x08: Secondary source active duration counter erase
0x10: Source 1 load supplied duration counter erase
0x20: Source 2 load supplied duration counter erase
AnnexeII-17.Setuptimer
Function 3, 6 and 16 Codes
Dec.
Address
Hex.
Address
Words
count
Description Unit
Source1timers
22016 5600 1 1FT: Primary Source fail timer sec.
22017 5601 1 1RT: Primary Source availability/stabilization timer sec.
Source2timers
22023 5607 1 2FT: Secondary Source fail timer sec.
22024 5608 1 2RT/2AT: Secondary Source availability/stabilization timer sec.
22025 5609 1 2CT: Secondary Source maintain request timer (cooldown timer) sec.
22027 560B 1 2ST: Secondary Source wait for start timer sec.
22028 560C 1 EET: Secondary Source engine exerciser timeout hours
22029 560D 1 EDT: Secondary Source engine exerciser duration sec.
Generaltimers
22030 560E 1 ODT: Dead band timer sec.
22031 560F 1 Limit_TON: Test on load is limited
0: unlimited
1: limited
22032 5610 1 TOT: Test on load duration timer sec.
