ATYSp - 542001E - SOCOMEC
800 to 3200 A
ThermalcurrentI
th
at 40°C 800A 1000 A 1250 A 1600 A 2000 A 2500 A 3200 A
Rated insulation voltage Ui (V) (power circuit) 1000 1000 1000 1000 1000 1000 1000
Rated impulse withstand voltage Uimp (kV) (power circuit) 12 12 12 12 12 12 12
Rated insulation voltage Ui (V) (control circuit) 300 300 300 300 300 300 300
Rated impulse withstand voltage Uimp (kV) (control circuit) 4 4 4 4 4 4 4
Rated operational currents I
e

Ratedvoltage Utilisationcategory A/B A/B A/B A/B A/B A/B A/B
415 VAC AC-21 A / AC-21 B 800/800 1000/1000 1250/1250 1600/1600 -/2000 -/2500 -/3200
415 VAC AC-22 A / AC-22 B 800/800 1000/1000 1250/1250 1600/1600 -/2000 -/2500 -/3200
415 VAC AC-23 A / AC-23 B 800/800 1000/1000 1250/1250 1250/1250 -/1600 -/1600 -/1600
500 VAC AC-21 A / AC-21 B 800/800 1000/1000 1250/1250 1600/1600 -/2000 -/2000 -/2000
500 VAC AC-22 A / AC-22 B 630/630 800/800 1000/1000 1600/1600
500 VAC AC-23 A / AC-23 B 630/630 630/630 800/800 1000/1000
690 VAC AC-21 A / AC-21 B 800/800 1000/1000 1250/1250 1600/1600 -/2000 -/2000 -/2000
690 VAC AC-22 A / AC-22 B 630/630 800/800 1000/1000 1000/1000
690 VAC AC-23 A / AC-23 B 400/400 630/630 800/800 800/800
220 VDC DC-21 A / DC-21 B 800/800 1000/1000 1250/1250 1250/1250
220 VDC DC-22 A / DC-22 B 800/800 1000/1000 1250/1250 1250/1250
220 VDC DC-23 A / DC-23 B 800/800 1000/1000 1250/1250 1250/1250
440 VDC
(1)
DC-21 A / DC-21 B 800/800 1000/1000 1250/1250 1250/1250
440 VDC
(1)
DC-22 A / DC-22 B 800/800 1000/1000 1250/1250 1250/1250
440 VDC
(1)
DC-23 A / DC-23 B 800/800 1000/1000 1250/1250 1250/1250
Rated operational currents I
e

Ratedvoltage Utilisationcategory
415 VAC AC-31 B 800 1000 1250 1600 2000 2500 3200
415 VAC AC-32 B 800 1000 1250 1250 2000 2000 2000
415 VAC AC-33 B 800 1000 800 1000 1250 1250 1250

Prospective fuse protected short-circuit withstand at 415 VAC(kA rms) 50 50 100 100 / / /
Prospective fuse protected short-circuit withstand at 690 VAC(kA rms) 50 50 50 / / / /
Associated fuse rating (A) 800 1000 1250 2x800

Current rated as short-time withstand I
cw
0,3s, 415 VAC (kA rms) 64 64 64 78 78 78 78
Current rated as short-time withstand I
cw
0,3s, 690 VAC (kA rms) / / / / / / /
Current rated as short-time withstand I
cw
1s, 415 VAC (kA rms) 35 35 35 50 50 50 50
Current rated as short-time withstand I
cw
1s, 690 VAC (kA rms) / / / / / / /
Power rated as closing short-circuit I
cm
at 415 VAC (peak kA) 73,5 73,5 73,5 105 105 105 105

Current rated as short-time withstand I
cw
30 ms (kA rms), 415 VAC / / / / / / /
Current rated as short-time withstand I
cw
60 ms (kA rms), 415 VAC 20 20 25 32 50 50 50
Power rated as closing short-circuit I
cm
at 415 VAC (peak kA) 40 40 52.5 67.2 105 105 105
Connection
Minimum Cu cable cross-section as per IEC 60947-1 (mm²) 2 x 185
Recommended Cu busbar cross-section (mm²) 2 x 50 x 5 2 x 63 x 5 2 x 60 x7 2 x 100 x 5 3 x 100 x 5 2 x 100 x 10 3 x 100 x 10
Maximum Cu cable cross-section (mm²) 2 x 300 4 x 185 4 x 185 6 x 185
Maximum Cu busbar width (mm) 63 63 63 100 100 100 100
Min./max. tightening torque (Nm) 9/13 9/13 20/26 40/45 40/45 40/45 40/45

Time of transfer I-II or II-I (s) 2.8 2.8 2.8 2.9 2.8 2.8 2.8
I-0 or II-0 (s) 1.4 1.4 1.4 1.4 1.8 1.8 1.8
Time of contact transfer ("black-out" I-II) minimum (s) 1.4 1.4 1.4 1.5 1 1 1
Power supply
Min./max. power (VAC) 166/332 166/332 166/332 166/332 166/332 166/332 166/332
Control supply power demand
Demand/rated power (VA) - ATyS r, ATyS d 460/184 460/184 460/184 460/230 812/322 812/322 812/322
Demand/rated power (VA) - ATyS t, g , p 482/206 482/206 482/206 482/252 834/344 834/344 834/344
Mechanical specifications
Durability (number of operating cycles) 4,000 4,000 4,000 3,000 3,000 3,000 3,000
Weight ATyS r 3 P / 4 P (kg) 27.9/ 32.2 28.4/ 32.9 28.9/ 33.6 33.1/ 39.4 50.7/ 61.6 50.7/ 61.6 61.0/ 75.3
Weight ATyS d 3 P / 4 P (kg) 28.5/ 32.8
29.0/ 33.5 29.5/ 34.2 33.7/ 40.0 51.3/ 62.2 51.3/ 62.2 61.6/ 75.9
Weight ATyS t, g, p 3 P / 4 P (kg) 29.0/ 33.3 29.5/ 34.0 30.0/ 34.7 34.2/ 40.5 51.8/ 62.7 51.8/ 62.7 62.1/ 76.4
(1) 3-pole device with 2 „+“ poles in series and 1 „-“ pole. 4-pole device with 2 poles in series by polarity
