DSC-F707
Address
Data
00 to 0C 0D to 27 28 to 48 49 to 74 75 to A6 A7 to DD DE to FF
90
CONTROL DOWN
CONTROL UP MENU INDEX FINEDER LCD
(KEY AD0)
(SW-362 board) (SW-362 board) (SW-362 board) (SW-362 board) (SW-362 board) (SW-362 board)
(IC102 is) (S353) (S353) (S352) (S351) (S354) (S354)
91
CONTROL RIGHT
CONTROL LEFT CONTROL SET
DISPLAY
(KEY AD1)
(SW-362 board) (SW-362 board) (SW-362 board) (SW-362 board)
No key input
(IC102 id) (S353) (S353) (S353) (S355)
92 AE LOCK SPOT METER
ONE-PUSH
WHT BAL
FOCUS FOCUS
WHITE BALANCE
MANUAL AUTO
(KEY AD2)
(CF50780 block) (CF50780 block)
(CF50780 block)
(CF50780 block)
(CF50780 block) (CF50780 block)
(IC102 if) (S301) (S302)
(S303)
(S304)
(S305) (S305)
93
+/– JOG DIAL NIGHT SHOT
NIGHT FRAMING
NIGHT SHOT
(EXPOSURE) EXECUTE ON
ON
NIGHT FRAMING
OFF
(KEY AD3)
(PW50780 block) (PW50780 block)
(TY-010 block) (TY-010 block)
(TY-010 block)
(IC102 ig)
(S404) (S406) (S301) (S301)
(S301)
5-44 E
8. Switch Check (2)
Page 2 Address 90 to 93
Using method:
1) Select page: 2, addresses: 90 to 93.
2) By discriminating the dispaly data, the pressed key can be
discriminated.
9. LED Check
Using method:
1) Select page: 2, address: 04, set data: 01, and press PAUSE
button.
2) Check that all LED are lit.
(SELF TIMER/REC, POWER, CHG, ACCESS LED)
3) Select page: 2, address: 04, set data: 00, and press PAUSE
button.
Page 2 Address 04 Data 01
Display Code
C:32:ss
C:13:ss
E:61:ss
E:91:ss
Countermeasure
Turn the power off and on again.
Format the “Memory Stick”.
Insert a new “Memory Stick”.
Checking of lens drive circuit.
Cause
Trouble with hardware.
Unformatted “Memory Stick” is inserted.
“Memory Stick” is broken.
When failed in the focus and zoom
initialization.
Abnormality when flash is being
charged.
Checking of flash unit or replacement
of flash unit.
Caution Display During Error
SYSTEM ERROR
FORMAT ERROR
MEMORY STICK ERROR
—
10.Self Diagnosis Code
