5-19
DSC-F707
8. Light Value Adjustment
Adjust the standard LV value.
Mode CAMERA
Subject Clear chart
(Standard picture frame with the
zoom lens at WIDE end)
Measurement Point Displayed data of page: 1 (Note
3) and page: F, address: 58
Measuring Instrument Adjusting remote commander
Adjustment Page F
Adjustment Address 56 to 58
Specified Value AE level 1: 0FE0 to 1020
AE level 2: 20 to 40
Note 1: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Note 2: Refer to “Picture Frame Setting” for YH and YL.
Note 3: The right four digits of the page: 1 displayed data of the
adjusting remote commander.
1:XX:XX
Displayed data
Adjusting method:
Order Page Address Data Procedure
1 0 01 01
2
Perform “Data setting during
camera system adjustment”.
(Refer to page 5-13)
36 2C01
4 6 90 00
5 6 91 00
6 6 92 YL (Note 2)
7 6 93 YH (Note 2)
8 6 01 79 Press PAUSE button.
96 07
Check the data changes to
“01”.
10 6 01 00 Press PAUSE button.
11 6 12 80
12 Wait for 1 second.
13 6 12 00
14 Wait for 4 seconds.
15 6 01 0D
Press PAUSE button.
(Note 4)
16 6 02
Check the data changes to
“01”.
17 0 03 06
18 1
Check that the displayed data
(Note 3) satisfies the AE
level 1 specified value.
19 F 58
Check that the displayed data
satisfies the AE level 2
specified value.
Note 4: The adjustment data will be automatically input to page:
F, address: 56 to 58.
Processing after Completing Adjustment:
Order Page Address Data Procedure
1 0 03 00
2 6 01 00 Press PAUSE button.
36 2C00
4 6 92 00
5 6 93 00
6
Release the data setting
performed at step 2.
(Refer to page 5-13)
7 0 01 00
To Next Page
