Sony Cyber-shot DSC-F707 User Manual

5-20
DSC-F707
9. Mixed Color Cancel Adjustment
To perform mixed color cancel adjustment based on data of each
color in color bar.
Mode CAMERA
Subject Color bar chart
(Standard picture frame with the
zoom lens at WIDE end)
Adjustment Page F
Adjustment Address 8E, 8F
Note 1: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Note 2: Refer to “Picture Frame Setting” for YH and YL.
Adjusting method:
Order Page Address Data Procedure
1 0 01 01
2
Perform “Data setting during
camera system adjustment”.
(Refer to page 5-13)
36 2C01
4 6 90 00
5 6 91 00
6 6 92 YL (Note 2)
7 6 93 YH (Note 2)
8 6 01 79 Press PAUSE button.
96 07
Check the data changes to
“01”.
10 6 01 00 Press PAUSE button.
11 6 01 D7 Press PAUSE button.
12 6 01 D5
Press PAUSE button.
(Note 3)
13 6 02
Check the data changes to
“01”.
Note 3: The adjustment data will be automatically input to page:
F, address: 8E and 8F.
Processing after Completing Adjustment:
Order Page Address Data Procedure
1 6 01 00 Press PAUSE button.
26 2C00
3 6 92 00
4 6 93 00
5
Release the data setting
performed at step 2.
(Refer to page 5-13)
6 0 01 00
10. Auto White Balance 3200K Standard Data Input (1)
Adjust the white balance standard data at 3200K.
Mode CAMERA
Subject Clear chart
(Standard picture frame with the
zoom lens at WIDE end)
Adjustment Page F
Adjustment Address 76 to 7D
Note 1: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Note 2: Refer to “Picture Frame Setting” for YH and YL.
Note 3: “Auto White Balance 3200K Standard Data Input (1)” is
available only once after the power is turned on. Turn the
power off, then on again if the adjustment is retried.
Adjusting method:
Order Page Address Data Procedure
1 0 01 01
2
Perform “Data setting during
camera system adjustment”.
(Refer to page 5-13)
36 2C01
4 6 90 00
5 6 91 00
6 6 92 YL (Note 2)
7 6 93 YH (Note 2)
8 6 01 79 Press PAUSE button.
96 07
Check the data changes to
“01”.
10 6 01 00 Press PAUSE button.
11 6 01 11 Press PAUSE button.
12 6 01 0B
Press PAUSE button.
(Note 4)
13 6 02
Check the data changes to
“01”.
Note 4: The adjustment data will be automatically input to page:
F, address: 76 to 7D.
Processing after Completing Adjustment:
Order Page Address Data Procedure
1 6 01 00 Press PAUSE button.
26 2C00
3 6 92 00
4 6 93 00
5
Release the data setting
performed at step 2.
(Refer to page 5-13)
6 0 01 00
