13. Auto White Balance 5800K Standard Data Input (1)
Adjust the white balance standard data at 5800K.
Mode CAMERA
Subject Clear chart
(Standard picture frame with the
zoom lens at WIDE end)
Filter Filter C14 for color temperature
correction
Adjustment Page F
Adjustment Address 80 to 87, 8A to 8D
Note 1: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Note 2: Refer to “Picture Frame Setting” for YH and YL.
Note 3: “Auto White Balance 5800K Standard Data Input (1)” is
available only once after the power is turned on. Turn the
power off, then on again if the adjustment is retried.
Adjusting method:
Order Page Address Data Procedure
1 Place the C14 filter on the lens.
2 0 01 01
3
Perform “Data setting during
camera system adjustment”.
(Refer to page 5-13)
46 2C01
5 6 90 00
6 6 91 00
7 6 92 YL (Note 2)
8 6 93 YH (Note 2)
9 6 01 79 Press PAUSE button.
10 6 07 Check the data changes to “01”.
11 6 01 00 Press PAUSE button.
12 F 8A 2A Press PAUSE button.
13 F 8B 80 Press PAUSE button.
14 F 8C 5D Press PAUSE button.
15 F 8D C0 Press PAUSE button.
16 6 01 A7 Press PAUSE button.
17 6 01 A5 Press PAUSE button. (Note 4)
18 6 02 Check the data changes to “01”.
Note 4: The adjustment data will be automatically input to page:
F, address: 80 to 87 and 8A to 8D.
Processing after Completing Adjustment:
Order Page Address Data Procedure
1 6 01 00 Press PAUSE button.
26 2C00
3 6 92 00
4 6 93 00
5
Release the data setting
performed at step 3.
(Refer to page 5-13)
6 0 01 00
7
Remove the C14 filter on the
lens.
14. Auto White Balance 5800K Standard Data Input (2)
Adjust the white balance standard data at 5800K.
Mode CAMERA
Subject Clear chart
(Standard picture frame with the
zoom lens at WIDE end)
Filter Filter C14 for color temperature
correction
Adjustment Page F
Adjustment Address B6, B7
Note 1: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Note 2: Refer to “Picture Frame Setting” for YH and YL.
Note 3: “Auto White Balance 5800K Standard Data Input (2)” is
available only once after the power is turned on. Turn the
power off, then on again if the adjustment is retried.
Adjusting method:
Order Page Address Data Procedure
1
Place the C14 filter on the
lens.
2 0 01 01
3
Perform “Data setting during
camera system adjustment”.
(Refer to page 5-13)
46 2C01
5 6 90 00
6 6 91 00
7 6 92 YL (Note 2)
8 6 93 YH (Note 2)
9 6 01 79 Press PAUSE button.
10 6 07
Check the data changes to
“01”.
11 6 01 00 Press PAUSE button.
12 6 01 A7 Press PAUSE button.
13 6 13 AB
14 6 01 D3
Press PAUSE button.
(Note 4)
15 6 02
Check the data changes to
“01”.
Note 4: The adjustment data will be automatically input to page:
F, address: B6 and B7.
Processing after Completing Adjustment:
Order Page Address Data Procedure
1 6 01 00 Press PAUSE button.
2 6 13 00
36 2C00
4 6 92 00
5 6 93 00
6
Release the data setting
performed at step 3. (Refer to
page 5-13)
7 0 01 00
8
Remove the C14 filter on the
lens.
