2-17
DCR-PC103E/PC104E/PC105/PC105E
2-22.LENS DEVICE (LSV-751A)
1
Screw
(M1.7
×
2.5),
lock ace, p2
3
Two screws
(M1.7
×
8),
lock ace, p2
4
Tapping screw
(M1.7
×
4)
qf
Lens device
(LSV-751A)
q;
Optical filter block
qa
Seal rubber (W)
qd
CCD section
2
CD-444 board
9
CD-444 board
8
CD shield sheet
qs
Remove the soldering
5
Two dowels
6
CD frame assembly
7
CD heat sink assembly
A
A
Caution
CD shield sheet
