5-14
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-PC103E/PC104E/PC105/PC105E
< SENSOR >
SE5201 1-476-807-31 SENSOR, ANGULAR VELOCITY (YAW SENSOR)
SE5202 1-476-807-41 SENSOR, ANGULAR VELOCITY (PITCH SENSOR)
************************************************************
A-7016-616-A FP-672 BOARD, COMPLETE
**********************
< PHOTO INTERRUPTER >
PH001 8-749-016-83 IC GP1S092HCPI
PH002 8-749-016-83 IC GP1S092HCPI
************************************************************
A-7016-987-A VC-319A BOARD, COMPLETE (PC105)(SERVICE)
A-7016-988-A VC-319B BOARD, COMPLETE
(PC104E,PC105E)(SERVICE)
A-7016-989-A VC-319C BOARD, COMPLETE
(PC103E)(SERVICE)
***************************************************
************************************************************
VC-319CD-444
Electrical parts list of the VC-319 board
are not shown.
Pages from 5-15 to 5-23 are not shown.
FP-672
