Sungrow SG10RS User Manual

67
• Please check the country supported by this product at http:// support.sungrow-
power.com/.
• Set Country/Region to the country/region where the inverter is installed. Oth-
erwise, the inverter may report a fault.
step 10 After a plant is successfully created, return to the App home page to view the plant
information.
- - End
6.5 Initializing the Device
The inverter is successfully connected to the router.
If there is no latest equipment upgrade package, skip steps 1 and 2.
The actual initializing procedure may differ due to different countries. Please follow the ac-
tual App guidance.
step 1 If a latest equipment upgrade package is available, the following prompt window pops up.
Tap UPDATE NOW to download the latest update package.
figure 6-3 Upgrade Reminder
step 2 After download, it would take around 15 minutes to update. After successful upgrade, the
screen will show the version numbers before and after the upgrade as well as the upgrade
time. Tap NEXT.
User Manual 6 Commissioning

Sungrow SG10RS Specifications

General

Rated Power	10 kW
Max. DC Voltage	1100 V
Number of MPPTs	2
Max. Efficiency	98.6%
Protection Rating	IP65
Start Voltage	180 V
Rated AC Output Power	10 kW
Max. AC Output Power	11 kW
Rated Output Voltage	230 V
Operating Temperature Range	-25°C to 60°C
Topology	Transformerless
Cooling Method	Natural Convection
Maximum Power Output	11 kW
Maximum Input Current	25 A
MPPT Voltage Range	160-1000 V
Max. DC Input Power	15 kW
AC Voltage Range	180-280 V
Humidity Range	0-100%
Communication	RS485
