9. Final Driving Mechanism

9-2

Precautions in Operation

Specification

Application oil: scooter gear oil

Recommended oil: KING MATE serial gear oils

Oil quantity: 180 c.c. (170 c.c. when replacing)

Torque value

Gear box cover 2.6~3.0kgf-m

Special tools

Bearing (6205) driver SYM-9615000-6205

Bearing (6205) puller SYM-9100400 HMA RA1 6205

Bearing (6203) driver SYM-9620000

Drive shaft & oil seal (25*40*8) socket SYM-9120200-HMA

Bearing (HK1516) driver SYM-9100200-HMA HK1516

Bearing (6204) driver SYM-9110400-6204

Oil seal drive 34*52*5 SYM-9125500-HMA

Inner bearing puller SYM-6204021 or SYM-6204022

Outer bearing puller SYM-6204001

Drive shaft install puller SYM-2341110- HMA RB1

Bearing install puller SYM-2341100

Clutch nut wrench SYM-9020200

Trouble Diagnosis

Engine can be started but motorcycle can not be moved.

 Damaged driving gear

 Burnt out driving gear

 Damaged driving belt.

Noise

 Worn or burnt gear

 Worn gear

Gear oil leaks

 Excessive gear oil.

 Worn or damage oil seal
