15. Steering / Front Wheel / Front Cushion
15-8
Front Cushion
Remove
Remove front cover, front under spoiler and front
fender.
Remove front wheel.
Remove front brake caliper.
Remove speedometer cable.
Loosen 4 bolts from steering stem.
Remove the front cushions.
Installation
Align the cover flange with upper level of the
cushion clamp, and then tighten bolts.
Torque value: 2.4~3.0kgf-m
Install the removed components in reverse order
of removal procedures.
