Sym JOYMAX 250 User Manual

3. Lubrication System
3-1
Mechanism Diagram ························· 3-1
Precautions in Operation ··················· 3-2
Troubleshooting ······························· 3-2
Engine Oil ········································ 3-3
Engine Oil Strainer Clean ·················· 3-3
Oil Pump ········································· 3-4
Gear Oil ··········································· 3-7
Mechanism Diagram
Valve Rocker Arm
Cam Shaft
Spray Lubrication
Spray Lubrication
Press-In Lubrication
Press-In Lubrication
Oil Route
Con-Rod
Oil Route
Oil Pump
Rotate Direction
Oil Strainer
3
