Sym JOYMAX 250 User Manual

5. Removal & Installation of Engine
5-6
With a bracket to support the engine to prevent
from it damage by falling down as removing the
engine.
Remove frame side engine hanger bolts (each
side 1 bolt), and then remove engine.
Engine Hanger
Removal
Remove the engine side bolts of engine hanger. (1
bolt on each side)
Remove the engine hanger.
Check if the engine hanger bush and cushion
rubber for damage. If so, replace with new ones.
Installation
Tighten the bolts and nuts of engine hanger.
Engine hanger nut:
Torque Value: 7.5~9.5kgf-m
To this chapter contents
Frame side bolt
Engine side bolt
