4. Fuel System
4-4
Carburetor Remove / Install
Removal
Remove luggage box.
Drain out fuel in the float chamber.
Disconnect the fuel hose, vacuum hose.
Disconnect the auto by-start and heater couplers.
Loosen the adjustment nut and fixing nut of throttle
valve cable, and release the cable from
carburetor.
Release the clamp strip of carburetor, and then
remove the carburetor.
Installation
Install in reverse order of removal procedures.
Vacuum Chamber
Removal
Loosen drain screw, and drain out residual fuel in
float chamber.
Remove screws (2 screws) of vacuum chamber
cover and the cover.
Remove compress spring and vacuum piston.
To Next Page
