128 TB9300 Installation and Operation Manual
© Tait International Limited April 2024
Appendix C TB9300 Cable Kits
Cable kits exist to provide replacement cables for the TB9300 subracks.
This means customers do not have to order individual cables.
Cable Kits
T01-01150-0002 - TB9300 Kit Cable Single 50W Channel Upgrade
This kit supports adding a second reciter and 50W PA to a TB9300 subrack.
It contains the following cables:
■ 1 X 225mm SMA RF Cable reciter to PA
■ 1 X 170mm 16-way cable PA to subrack board
■ 1 X 85mm 20-way cable reciter to subrack board
■ Also included are a clamp and screw to secure the PA, and a cable clamp
to secure the PA power cable
T01-01150-0004 - TB9300 Kit Cable Single 100W Channel Upgrade
This kit supports adding a second reciter and 100W PA to a TB9300
subrack. It contains the following cables:
■ 1 X 225mm SMA RF Cable reciter to PA
■ 1 X 200mm 16-way cable PMU and PA to subrack board
■ 1 X 85mm 20-way cable reciter to subrack board
■ 1 X 130mm Power cable from PMU to subrack board
■ Also included are a clamp and screw to secure the PA, and a cable clamp
to secure the PA power cable
T01-01150-0006 - TB9300 Single 50W Replacement Cable Set
This kit contains a set of replacement cables for a single 50W TB9300
subrack. It contains the following cables:
■ 1 X 225mm SMA RF Cable reciter to PA
■ 1 X 100mm 16-way cable PMU to subrack board
■ 1 X 85mm 16-way cable PMU to subrack board
■ 1 X 90mm 20-way cable reciter to subrack board
■ 1 X 130mm Power cable from PMU to subrack board
■ Also included are 2 clamps and 2 screws
